Document Overview
Title: ISO9001:2015-certified quality system documentation for the AMZ 101 P24 Series intelligent control terminal.
Purpose: Provides detailed technical specifications, hardware/software descriptions, reliability test results, and company/product information.
Key Sections
1. Contact Information
Company: Shenzhen Kinseal Intelligent Control Technology Co., Ltd.
Address: Floor 3, Yaoji Building 1, Xinhetongfufu Industrial Zone, Fuhai Street, Bao'an District, Shenzhen.
2. Product Description
Model Series:
AMZ101P24W01RES, AMZ101P24W01RDS, AMZ101P24W01REE, AMZ101P24W01RED.
Variations include differences in serial ports (RS232/RS485), touchscreen type (resistive/capacitive), and storage.
Key Features:
Power: DC 10–30V input with reverse polarity protection.
Display: 10.1-inch TN TFT LCD (1024x600 resolution, 250 cd/m² brightness).
Touchscreen: 4-wire resistive (optional capacitive support).
Storage: 128 MB SPI NAND Flash.
Communication:
COM1: RS232/RS485 (selectable via module).
COM2: RS232/RS485 (selectable via module).
Interfaces: USB 2.0 (Micro USB and Type-A), SD card slot.
RTC: Built-in real-time clock.
Software Download: Supports USB, U disk, and SD card.
3. Hardware Specifications
Dimensions:
Overall size: 257.7 × 148.3 × 22 mm.
Display area: 222.7 × 125.3 mm.
Panel cutout: 247.5 × 120.4 mm.
Weight: 280g.
Environmental Ratings:
Operating temperature: -20°C to 50°C.
Storage temperature: -40°C to 70°C.
Humidity: 10–90% RH (non-condensing).
Protection: IP65 front panel (with cabinet), IP20 rear panel.
4. Reliability Tests
ESD Test (IEC 61000-4-2):
±8kV contact discharge; no system reset or display abnormalities.
High/Low Temperature Aging Test:
Operating range validated (-20°C to 50°C).
Electrical Fast Transient (EFT) Test: ±4kV.
Lightning Surge Test: ±2kV surge protection.
5. Software & Development
Download Methods: USB, U disk, SD card.
Configuration Software: Includes protocol configuration tools and development software (details in Section 7).
6. Appendices
Pin Definitions: Detailed terminal pin layouts for power, communication ports (RS232/RS485), USB, and SD card.
Change Records: Version history and review/approval logs (tables for traceability).
Compliance & Certifications
Standards:
CE & ROHS compliant (EN61000-6-2:2005, EN61000-6-4:2007).
ESD, EFT, and surge protection meet industrial requirements.
Notes
File Number: JXZK-WI--ED-26-11.
Revision Control: Includes change records and review/approval tables for documentation updates.
This document serves as a comprehensive guide for engineers, purchasers, and technical teams to understand the product's capabilities, installation requirements, and compliance with industrial standards.
LCD resolution: 1024X600
USB1: Micro USB
USB2: TYPE-A
LCD: TN TFT LCD, 250cd/m2
COM1: communication RS232/RS485 communication (2 choose 1)
COM2: communication RS232/RS485 (2 choose 1)
Storage: 128Mbyte SPI NAND FLASH
If the quantity of orders is not very big, we could send them to you by express delivery, such as TNT, DHL, UPS, OR EMS, etc.
If an order is big, we will advise you to use Air Shipping or Sea Shipping through your nominated forwarder agent. Our long-term cooperated agent is also available.
